北京n型碳化硅_北京n型碳化硅襯底_蘇州n型碳化硅_豪麥瑞供_蘇州豪麥瑞材料科技有限公司專業從事氧化鋁球,氧化鋯球,陶瓷精加工,紡織陶瓷拋光加工業務.聯系電話：18962527682 網址：www.homraymaterial.cn

碳化硅半導體是新一代寬禁帶半導體，它具有熱導率高，與GaN晶格失配小等優勢，非常適合用作發光二極管，大功率電力電子材料。

采用碳化硅作襯底的LED器件亮度更高、能耗更低、壽命更長、單位芯片面積更小，且在大功率LED方面具有非常大的優勢。此外，碳化硅除了用作LED襯底，它還可以制造高耐壓、大功率電力電子器件如肖特基二極管（SBD/JBS）、絕緣柵雙極型晶體管（IGBT）,晶閘管（GTO）、金屬氧化物半導體場效應晶體管（MOSFET）等，用于智能電網、太陽能并網、電動汽車等行業。

從整體上看，碳化硅半導體完整產業鏈包括：碳化硅原料-晶錠-襯底-外延-芯片-器件-模塊。

我們公司進口碳化硅晶圓，為我們的客戶提供所需的材料，讓客戶在這樣行業里促進技術的快速擴展。

產品介紹：

n-type SiC Substrate

PRODUCT DESCRIPTIONS

The Materials Business Unit produces a wide assortment of n-type conductive SiC products ranging in wafer diameters up to 150mm. This material is manufactured upon a high-volume platform process that provides our customers the highest degree of material quality, supply assurance and economies of scale.

Part Number	Description
W4NRF0X-0200	4H-SiC, n-type, Research Grade, 100mm, On-Axis, 0.013-2.0 ohm-cm, Standard MPD, 500um Thick, DoubleSided Polish Si Face CMP Epi Ready, Bare Substrate
W4NRF4C-U200	4H-SiC, n-type, Research Grade, 100mm, 4° Off-Axis, 0.015-0.028 ohm-cm, Ultra Low MPD ≤1/cm2, 350um Thick, Double-Sided Polish Si Face CMP Epi Ready, Bare Substrate
W4NPF4C-U200	4H-SiC, n-type, Production Grade, 100mm, 4° Off-Axis, 0.015-0.028 ohm-cm, Ultra Low MPD ≤1/cm2, 350um Thick, Double-Sided Polish Si Face CMP Epi Ready, Bare Substrate
W4NRF4C-B200	4H-SiC, n-type, Research Grade, 100mm, 4° Off-Axis, 0.015-0.028 ohm-cm, Ultra Low MPD ≤1/cm2, Low BPD ≤1500/cm2, 350um Thick, Double Sided Polish Si Face CMP Epi Ready, Bare Substrate
W4NPF4C-B200	4H-SiC, n-type, Production Grade, 100mm, 4° Off-Axis, 0.015-0.028 ohm-cm, Ultra Low MPD ≤1/cm2, Low BPD ≤1500/cm2, 350um Thick, Double-Sided Polish Si Face CMP Epi Ready, Bare Substrate
W4NRG4C-C1-V200	4H-SiC, n-type, Research Grade, 150mm, 4° Off-Axis, 0.015-0.028 ohm-cm, Very Low MPD ≤5/cm2, 350um Thick w/ 47.5mm Flat, Double-Sided Polish Si Face CMP Epi Ready, Bare Substrate
W4NPG4C-C1-V200	4H-SiC, n-type, Production Grade, 150mm, 4° Off-Axis, 0.015-0.028 ohm-cm, Very Low MPD ≤5/cm2, 350um Thick w/ 47.5mm Flat, Double-Sided Polish Si Face CMP Epi Ready, Bare Substrate
W4NRG4C-C1-U200	4H-SiC, n-type, Research Grade, 150mm, 4° Off-Axis, 0.015-0.028 ohm-cm, Ultra Low MPD ≤1/cm2, 350um Thick w/ 47.5mm Flat, Double-Sided Polish Si Face CMP Epi Ready, Bare Substrate
W4NPG4C-C1-U200	4H-SiC, n-type, Production Grade, 150mm, 4° Off-Axis, 0.015-0.028 ohm-cm, Ultra Low MPD ≤1/cm2, 350um Thick w/ 47.5mm Flat, Double-Sided Polish Si Face CMP Epi Ready, Bare Substrate

*C-faced polished wafers and 150mm LBPD substrates available upon request, lead times dependent on volume and requirements

FLAT LENGTH

Linear dimension of the flat measured with ANSI-certified digital calipers on a sample of one wafer per ingot

PRIMARY FLAT

The flat of the longest length on the wafer, oriented such that the chord is parallel with a specified low-index crystal plane.

PRIMARY FLAT ORIENTATION

The primary flat is the {1010} plane with the flat face parallel to the <1120> direction. Measured with Laue back reflection technique.

SECONDARY FLAT

A flat of shorter length than the primary flat, whose position with respect to the primary flat identifies the face of the wafer. Not applicable to 150mm wafers.

SECONDARY FLAT ORIENTATION

The secondary flat is the {11-20} plane with the flat face parallel to the <1010> direction. Measured with Laue back reflection technique.

橢圓: XXXXXX-XX

MARKING

For silicon-face polished material, the carbon face of each individual wafer is laser-marked with OCR-compatible font, similar to definitions and characteristics in SEMI M12. For carbonface-polished material, the silicon face of each individual wafer is laser-marked.

PRODUCT SPECIFICATIONS

100mm Diameter n-type Substrates
Diameter	100.0 mm +0.0/-0.5 mm
Thickness
On-axis	500 μm ± 25 μm
Off-axis	350.0 μm ± 25.0 μm
Dopant	Nitrogen
Primary flat length	32.5 mm ± 2.0 mm
Secondary flat length	18.0 mm ± 2.0 mm
Surface orientation
On-axis	{0001} ± 0.25?
Off-axis	4.0? toward <1120> ± 0.5?
Surface finish	Back face optical polish, epi-face CMP
Orthogonal misorientation	± 5.0?
Primary flat orientation	<1120> ± 5.0?
Secondary flat orientation	90.0? CW from primary ± 5.0?, silicon face up
TTV	≤15 microns, full substrate
Warp	≤45 microns, full substrate
LTV (average, 1 cm2 site)	≤4 microns, full substrate
Edge chips by diffuse lighting
Production-grade	none permitted ≥0.5mm width and depth
Research-grade	qty. 2 ≥1.0 mm width and depth

150mm Diameter n-type Substrates
Diameter	150.0 mm ± 0.25 mm
Thickness
C1 specification	350 μm ± 25 μm
Dopant	Nitrogen
Primary flat length	47.5 mm ± 1.5 mm
Secondary flat length	None
Surface orientation	4.0? toward <11-20> ± 0.5?
Surface finish	Back face optical polish, epi-face CMP
Orthogonal misorientation	± 5.0?
Primary flat orientation	<11-20> ± 5?
Secondary flat orientation	N/A
TTV	≤10 μm
Warp
Production-grade	≤40 μm
Research-grade	≤60 μm
LTV (average, 1 cm2 site)
Production-grade	≤2 μm
Research-grade	≤4 μm
Edge chips by diffuse lighting
Production-grade	none permitted ≥0.5mm width and depth
Research-grade	qty. 2 ≥1.0 mm width and depth

4H-N碳化硅晶片.jpg 6H-N碳化硅晶片 .jpg 6H-SI碳化硅晶片 .jpg
